Graphical User Interface

The Main window of the interface XEchelle, presented in Figure is created with the command:

Midas...> CREATE/GUI ECHELLE

To exit XEchelle you must select in the menu the option or push the button located at the lower-right corner of the main panel. The Main Panel of the interface includes the following elements:

a)

A menu bar

a)

A directory and file browser

a)

A calibration and reduction steps area

c)

A short help

c)

A set of push-buttons


Figure: Main window of the GUI XEchelle

• Initializing Keywords
• Short Help
• Sending Commands
• On-line HELP facility
• Entering File Names
• Dialog Windows
• Saving and Loading Session Parameters
• Performing Batch Reduction
